A high-end residence in Aspen required a contoured marble surround with a custom mantel shelf. Using Proliner and LT-2D3D scans, we captured every rebate, angled return, and shelf overhang. The fabricator cut and installed the marble surround flawlessly—no on-site adjustments and a perfect fit on the first try.
Service
Fireplace Templating
Our fireplace templating service provides ultra-precise digital captures for hearths, surrounds, and mantel installations—whether you’re working with stone, tile, or metal finishes. We document every angle, depth, and edge to ensure your fabricator can cut and install each component perfectly.
End-to-end digital templates for hearth, surround, and mantel profiles
Accurate corner and return measurements for seamless joints
DXF, PDF, and optional 3D files delivered ready for fabrication
Why Precision Matters
- Perfect Hearth Fit: Eliminates gaps between the fireplace opening and hearth, preventing heat loss and uneven surfaces.
- Seamless Surround Joints: Pinpoint corner returns and mitered edges mean no visible seams or misalignments.
- Mantel Alignment: Ensures mantel shelves and legs sit flush against walls, avoiding installation headaches.
- Reduced Field Cuts: Accurate templates minimize on-site trimming, saving time and material.
Our Technology
- Prodim Proliner Scanner: Handheld system captures complex profiles, rebates, and angled returns with ±0.5 mm accuracy.
- LT-2D3D Laser Templator: Ideal for full 3D surfaces and recessed hearth areas, ensuring depth and planar accuracy.
- Fusion 360 3D Modeling (optional): Visualize the complete surround assembly—including mantel details—before any cutting begins.
Step-by-Step Process
Initial Consultation
– Discuss fireplace style, material type, surround thickness, and mantel dimensions via call or form.On-Site Digital Scan
– Capture hearth plane, surround walls, and mantel overhangs in 30–45 minutes using Proliner and laser tools.Validation & QA
– Compare scans against your drawings; resolve discrepancies on the spot.File Preparation
– Produce labeled DXF templates, 1:1 PDF prints, and optional 3D models for review.Client Sign-Off
– Approve the final templates via email or our digital portal before fabrication.Revisions & Support
– Complimentary minor tweaks within 72 hours; small fee thereafter.
What You’ll Receive
- DXF Files: Ready for CNC or manual layout of hearth, surround, and mantel.
- PDF Templates: Printable, full-scale sheets for on-site verification.
- Site Photos: High-res images of hearth recesses, wall returns, and mantel interfaces.
- Sign-Off Documentation: Confirms accuracy before any materials are cut.
- Miter & Return Details: Exact corner angles and return depths for flawless joints
- Optional 3D Models: Full surround assembly for visualization and approval.
Turnaround & Pricing
- Standard Delivery: 24 hours after on-site capture
- Rush Service: 12 hours for priority projects
- Simple hearth & surround: from €150
- Fireplace with mantel templating: from €250
- Complex or multi-plane surrounds: custom quote
Frequently Asked Questions
Do walls need to be finished before templating?
Yes—painted or finished wall surfaces ensure accurate measurements and proper template fit.
Can you template angled hearths or raised platforms?
Absolutely; our laser tools capture any plane or elevation change precisely.
What if my surround material is thicker than standard?
Specify material thickness during consultation; we’ll adjust the capture offsets accordingly.
How do I schedule a scan?
Book instantly via our Google Calendar link or call us
Case Study: Luxury Marble Fireplace
